How many kinds of overlapping methods for carbon fiber structural reinforcement?

There are 2 common lap methods

1. Lap in force direction

That is, overlapping

When the number of layers pasted in the direction of force is 1-2, the length of lap at each end is not less than 200 mm

If pasting more than 3 layers, the length of lap at each end should not rain 300 mm

2. Lap in non-forced direction

Which is the overlapping of horizontal stripes

For laps in the non-stressed direction, the length of the lap at each end may be 100 mm
